ACT2航空級芳綸紙蜂窩芯
Description說明:
ACT2aerospace grade aramid honeycomb is manufactured from Nomex? aerospace grade paper and coated with a heat resistant phenolic resin(MIL-R-9299).
ACT2航空級芳綸紙蜂窩芯由Nomex? 航空級芳綸紙浸漬耐熱酚醛樹脂（MIL-R-9299）固化而成。
Applications應用:
Excellent strength and stiffness are valued: ACT2 honeycomb uses include aircraft galleys, flooring, interior panel, radome, fuel tanks, helicopter rotor blades, military shelters,Secondary structurepanel in all the plane.
優越的強度和剛度值：ACT2蜂窩用途包括飛機廚房、地板、內飾板、雷達、油箱、直升機槳葉、軍用方艙以及飛機次承力結構件。
Characteristics特性: ·High strength to weight ratio比強度高 ·High toughness to weight ratio比剛度高 ·Excellent flame resistance, low smoke generation優越的阻燃性能，低煙性 ·Good water resistance良好的耐水性能 ·Good thermal stability and strength retention良好的熱穩定性和強度保留率 ·Superior dielectric properties優越的電性能 ·Strong bonding surface for sandwich construction對三明治板材而言，有著優越的粘結面 ·Corrosion resistant, will not like aluminum honeycomb core耐腐蝕，不像鋁蜂窩芯 ·Good heat, and noise insulation優良的隔音隔熱性能 | Availability可用性: ACT2 is available as blocks, sheets, or pieces cut to dimension.可以提供蜂窩塊、片材或指定尺寸的片 Cell Sizes孔格尺寸: 3.2mm, 4.8mm, 4.8EX, 6.4mm,7.8mm Densities密度范圍: 32-128 kg/m3 Standard Dimensions標準尺寸: 1.2m x 2.4m; (Max最大尺寸:1.3m*2.6m) Thickness厚度范圍:2mm-885mm, Tolerances誤差: Density密度±10% Cell size孔格尺寸±10%, Thickness厚度誤差: ±0.15mm (< 50mm) Length and Width of Slices長、寬誤差: 0mm to +50mm |
ACT2Honeycomb Mechanical Properties
ACT2芳綸紙蜂窩芯機械性能表
Core type | Density ( kg/m3) | Stab.comp.str (Mpa) | L Shear Properties(Mpa) | W Shear Properties(Mpa) | |||||||
Strength | Modulus | Strength | Modulus | ||||||||
Typ | Min Ind | Typ | Min Ind | Typ | Min Ind | Typ | Min Ind | Typ | Min Ind | ||
ACT2-3.2-29 | 29 | 0.77 | 0.60 | 0.56 | 0.47 | 25.9 | 17.4 | 0.35 | 0.30 | 14.5 | 11.3 |
ACT2-3.2-48 | 48 | 2.35 | 1.92 | 1.22 | 1.03 | 44.5 | 34.5 | 0.73 | 0.61 | 27.1 | 20.9 |
ACT2-3.2-64 | 64 | 3.88 | 3.22 | 1.72 | 1.55 | 61.0 | 54.0 | 0.99 | 0.82 | 34.0 | 25.0 |
ACT2-3.2-80(E) | 80 | 6.67 | 4.49 | 1.92 | 1.65 | 66.1 | 52.3 | 1.20 | 0.97 | 43.9 | 36.3 |
ACT2-3.2-80 | 80 | 5.19 | 4.69 | 2.22 | 1.95 | 71.0 | 64.0 | 1.23 | 1.05 | 38.4 | 34.0 |
ACT2-3.2-96(E) | 96 | 8.99 | 8.78 | 2.49 | 2.25 | 82.8 | 77.5 | 1.73 | 1.67 | 59.1 | 55.5 |
ACT2-4.8-40 | 40 | 1.63 | 1.46 | 0.95 | 0.92 | 38.0 | 36.3 | 0.55 | 0.52 | 23.9 | 22.5 |
ACT2-4.8-48 | 48 | 2.45 | 1.86 | 1.24 | 1.02 | 41.3 | 34.0 | 0.77 | 0.60 | 30.0 | 18.0 |
ACT2-4.8-72 | 72 | 5.28 | 4.60 | 1.70 | 57.1 | 47.5 | 1.09 | 0.80 | 40.5 | 23.2 | |
ACT2-4.8EX-48 | 48 | 2.20 | 1.80 | 0.79 | 0.62 | 20.6 | 16.1 | 0.87 | 0.72 | 42.0 | 34.0 |
The above data is based on limited testing of specimens 12.7mm(0.5 inch)tested at room temperature.
以上數據基于室溫條件下，對12.7mm(0.5inch) 樣品測試所得到的數據。
NOTICE: ACT Materials endeavors to ensure the information and data in this document are correct, up to date, and fully representative of the performance of the product as a whole. It is the responsibility of the purchasing party to perform the necessary studies and testing to ensure the product purchased is suitable for the intended purpose. ACT Materials does not accept liability for damage or losses related to the use of this product as the conditions of use are not within ACT control.
特一新材公司努力采取行動，以確保本文檔中的信息和數據是正確的、最新的、充分的代表整個產品的性能。采購方的責任在購買前，需執行必要的研究和測試，以確保購買的產品適合預期的目的。在失控條件下，使用本產品，特一新材公司不接受賠償責任或損失相關。
